SR3025 Domestic heating boiler Thermal Training Equipment Educational Equipment

Brand: ShouldShine

Model:SR3025

1. Learning Objectives / Experiments

- function of an oil burner

- operation of a heating boiler with an oil burner

- burner adjustment during operation

- temperature measurements in different areas of the combustion chamber

- calculation of the heating capacity of a heating boiler

- function of a plate heat exchanger

- temperature distributions in a plate heat exchanger

2. Specification

[1] Functional heating boiler with oil burner

[2] Boiler with control unit

[3] Heating and cooling circuit equipped with expansion vessel, pump, boiler safety group,
thermometers, water meter, heat exchanger

[4] Transparent oil tank with filling and bleed connections

[5] Dissipation of generated heat via plate heat exchanger and cold water connection

3. Technical Data

Boiler
- nominal rating: 17...21kW
- control unit with temperature limiter
Burner
- nominal power: approx. 18kW
Pump
- power consumption: 70W
- max. flow rate: 60L/min
- max. head: 4m
Plate heat exchanger: 3kW, 10 plates
Boiler safety group in accordance
- 2.5bar
- 50kW
Oil tank: 15L
Water meter: 2.5m³/h
Measuring ranges
- temperature: 4x 0...120°C
Dimensions and Weight
LxWxH: 1510x810x1620mm
Weight: approx. 230kg
230V, 50/60Hz, 1 phase or 120V, 60Hz, 1 phase
Water connection, drain
Ventilation, exhaust gas routing required

Arrange delivery within 45 days upon receipt of payment.

Please see below photo for detailed package.
